High Speed Rail Roadway Overpass



FACTS OF INTEREST

YEAR: 2007



SPECIFICATIONS:



LENGTH:

10,83 kms.



KIND OF WORK:

Double track of UIC wide High-Speed Rail Roadway



(Roadway total wide, 14,00 m).



Maximum speed: 350 km/h



Traffic type: Passengers.



1 P.A.E.T.:

Overtaking and parking of trains post (sidetrack) with four tracks and platforms, 2.239,50 m long

(section wide variable between 26,7 and 31,7 m).



STRUCTURES:

8 Underpasses



1 Overpass



3 Viaducts:



« Rambla de Suge Viaductl »: 86 m long, 3 spans, 38 m maximum span and 1.204,0 m² area.



« Barranco de los Prados de Segovia Viaduct »: 102,75 m long, 3 spans, 44,75 m maximum span

and 1.438,5 m² area.



« Viaducto sobre la Autovía A-35 »: 196 m long, 6 spans, 35 m maximum span and 2.744,0 m² area.



CONTRACT BUDGET: 1.322.868,18 € (VAT included)



ESTIMATED BUDGET TO INVITE CONSTRUCTION TENDERS: 45.935.772,64 € (VAT included)



PERIOD PROVIDED FOR CONSTRUCTION: 24 months.


CLIENT: SPANISH MINISTRY OF PUBLIC WORKS. Railroads Administration.
