Reinosa South Interchange Overpass


FACTS OF INTEREST:

AÑO: 2002



CARACTERÍSTICAS TÉCNICAS:



LENGTH:

17,92 kilometers



KIND OF WORK:

Motorway with 10,00 m wide median and dual 2 lanes driveways (total width of each driveway is 11,50 m).



Replacement of 3.30 km of single carriageway 12 meters wide. Including 2 intersections and level 2 roundabouts.



Design speed:100 km/h



INTERCHANGES:  4

«Reinosa North Interchange»: Diamond type with two roundabouts.



«Reinosa South Interchange»: Diamond type with two roundabouts.



«Fombellida Interchange»: Diamond type with a roundabout and an intersection.



«Polientes Interchange»: Two partial interchanges with two traffic movementns each.



STRUCTURES:

2 Overpasses, 18 Underpasses and 3 Bridges.



3 Viaducts:



«Ebro river Viaduct»: 2 decks, 166,00 m long, 5 spans, 36,00 m maximum span, 11,30 m wide, 3.751,60 m2 area



«Izadilla river Viaduct»: 2 decks, 58,096 m long, 2 spans, 29,048 m maximum span, 11,30 m wide, 1.312,97 m2 area.



«Mariantes river Viaduct»: 2 decks, 378,00 m long, 11 spans, 36,00 m, maximun span, 11,30 m wide, 8.542,80 m2 area.



CONTRACT BUDGET: 1.365.534,46 € (VAT included)

CONSTRUCTION ESTIMATED BUDGET TO INVITE TENDERS: 86.403.083,56 € (VAT included)



PERIOD PROVIDED FOR CONSTRUCTION: 30 months.


CLIENT: Spanish Ministry of Public Works. General Management of Roads.
