Viaduct over the Perral river (189 m length)


FACTS OF INTEREST:

YEAR: 2012 (In Edition)



SPECIFICATIONS:



LENGTH:

13,15 kilómetros

KIND OF WORK:

Divided highway: dual 2 lanes (total width of each driveway 11,60 m).



Project velocity: 120 km/h



INTERCHANGE:  3

«Baélls interchange»: Diamond type with 2 roundabouts



« Estopiñán interchange»: Diamond type with 2 roundabouts



« Enlace de Purroy interchange »: Diamond type with 2 roundabouts.


STRUCTURES:

1 Viaduct over the « Obagas ravine» with just one deck for the two driveways, 332 m length, 6 veins, 72 m maximum light, 25,0 m width, area 8.300,0 m2.


2 Overpasses


11 Underpasses



BUDGET OF PROJECT: 1.771.053,20 € (TAXES INCLUDED)



BUDGET ESTIMATED TO INVITED TENDERS OF THE WORKS: 65.000.000,00 € (TAXES INCLUDED)


CLIENT: Spanish Ministry of Public Works. General Management of Roads.
