Tina Menor River Viaduct (Lenth = 378,50 m)


FACTS OF INTEREST

YEAR: 2003



TECHNICAL FEATURES:



LENGTH:

15,79 Km.



KIND OF WORK:

Motorway with 9,00 m wide median dual two lanes driveway

(total width of each driveway is 11,50 m).



INTERCHANGES:  4

« Roiz Interchange »: Diamond type with 1 roundabout.



« San Vicente Interchange »: Diamond type with 2 roundabouts.



« Pesués Interchange »: Diamond type.



« Unquera Interchange »: Diamond type with 2 roundabouts.



STRUCTURES:

8 Overpasses, 1 Underpass, 5 Bridges and 7 Viaducts:



« Escudo river viaduct »: one deck, 30,00 m wide, 229 m long, 15,90 m maximum span,15 spans supported

on an arc 126,90 m long, 6.870,00 m² area.



« La Acebosa Viaduct»: 2 decks, 14,40 m wide, 208,6 m long, 5 spans, 45,00 m maximum span, 6.007,68 m² area



« Gandarilla River Viaduct » : 2 decks, 14,80 m wide, 84 m long, 3 spans, 28,00 m maximum span, 2.486,40 m² area



« Tina Menor River Viaduct » : 1 deck, 30,00 m wide, 378,5 m long, 4 spans, 125,00 m maximum span,

11.355,00 m² area



« Tina Mayor River Viaduct »: 2 decks, 14,40 m wide, 125,38 m long, 3 spans, 43,25 m maximum span,

3.610,94 m² area



CONTRACT BUDGET: 2.549.224,20 € (VAT included)

CONSTRUCTION BUDGET: 101.144.204,77 € (VAT included)



PERIOD PROVIDED FOR WORK PERFORMANCE: 36 months.


CLIENT: Spanish Ministry of Public Works. General Management of Roads.
